getLight 1092 SET Deuterium-Halogen Light Source

The getLight 1092 SET is a combined Deuterium and halogen light source, which can be used for UV/VIS/NIR applications. The getLight 1092 SET has a SMA905 connector to be used with fiber optic cables and bundles. For optimal coupling an adjustable focus lens assembly is included. The light source supplies a continuous spectrum with high efficiency and highest stability in the UV, visible and near-infrared range from 215-2000 nm.
The getLight 1092 SET was developed based on the shine-through principle, in which the halogen light is focused through a small diameter aperture in the deuterium bulb.
For pure UV applications the getLight-DS (only Deuterium) source is available.
The standard getLight 1092 SET light sources have a special UV longpass filter (>220nm) implemented to protect the fibers from solarizing. For applications that require a spectral range below 220 nm a Deep UV bulb is available, in which no UV longpass filter is included. For these Deep-UV measurements (from 190nm) the getLight-D(H)S-DUV may be ordered.
For all Deuterium Light Sources solarization resistant fibers (-SR) are recommended, for the DUV lamp special solarization resistant fibers (-SR) are required.
The output of the getLight 1092 SET is optimized for fibers(bundles) with a diameter up to 600 µm, for larger diameter fiber bundles the getLight 1092 SET SMA connector focal point can be manually adapted to uniformly fill a larger core diameter fiber cable or bundles.
In all getLight-Deuterium sources an integrated TTL-shutter and filter holder for filters of up to 50x50x6.5 mm are implemented.

Illumination technology : deuterium lamp, halogen lamp
Spectrum : UV, visible, NIR
Other characteristics : compact
Wavelength : Min.:
Output power : Min.:
