Crystal oscillatorHC-49/S

● Low Profile
● Thru-Hole Package
● Multiple Package Height
● Low Cost

Calibration Frequency Tolerance:
±30ppm ~ ±50ppm @ 25°C

Frequency Stability over Temp.:
±30ppm ~ ±50ppm

Operating Temperature:
0~+70°C, -40~+85°C (Option)

Storage Temperature:
-55°C ~ +125°C

Load Capacitance:
10 TO 32pF OR Series

Shunt Capacitance:
7pF Max

Equivalent Series Resistance:
50~200 Ohms Max

Drive Level:
0.1 mW Typical, 1mW Max

Aging:
± 5.0ppm per year

Type : crystal
Technology : MEMS
Frequency : Min.:
