Meets EPACT 2005 and exceeds ASHRAE 90.1-1999 efficiency standards.
Simplicity® controls.
Inherently protected condenser fan motors.
2-pipe and 4-pipe configurations available.
Five-minute anti-short cycle timer and minimum compressor run time.
Standard operation to 40°F. Factory or field-installed low-ambient VFD control to 0°F.
Factory-installed disconnects, convenience outlet and technicoated coil option.
Scroll compressors provide both high efficiency and reliability.
Condenser coils constructed of MicroChannel aluminum tube, aluminum fins for durability and long lasting and efficient operation.
Crankcase heaters that will be de-energized when the compressor is operating.
Self-contained high and low pressure controls.
Solid state or internal line break compressor motor protection.
Class 2, 24-volt thermostat control circuit.
A filter drier is shipped in the unit’s control box for field installation in the liquid line. Copper stub-outs are factory-mounted on the suction and liquid lines to simplify the field piping connections.
Compressor staging for capacity reduction provides more economical operation and even temperature levels within the conditioned space (except 7.5 ton).
Material : copper
