Concrete product making machineYPM-1300

Brief Introductrion:

1. The automatic wood pallet nail machine equipment including auto stacking platform , wood pallet lifting device and flip picking device .

2. High Degree automation , smooth closely process , complete nailing and stacking in one time .

3. The whole machine use full automatic system , PLC control , simple touch screen operation , accurate pinning position with high efficiency .

Technical Parameters:

Product name

Automatic wooden pallet making machine

Model

YPM-1300

Working mode

Automatic feeding of automatic nail stacking

Operation mode

PLC Control

Operational mode

Pneumatic operation

Voltage and power

380V three-phase 1.5kw Servo motor

Air pressure

0.8MPA

Tank size

0.2 cubic

Nail gun speed

7 times /second.

Production effciency

3 tray /min

Apply a nail

Less than 80mm

Weight

2000kg

Size

Host machine 2000*2800*2600mm

Stacking 2600*1900*1600

Finished product : for concrete products
Other characteristics : automatic
