working speed : 15000 mm/m
spindle speed: 24000 rpm.
working size : 1500x3000x200 mm.
Applications: Its suitable for wood processing like making doors, windows, cabinet, wood furniture, etc. Also can make acrylic stand, signs, and musical instruments. Soft metal like aluminum and copper also can be processed very well.
High Quality Main Parts:
1)Original Italy HSD 9KW ATC Spindle compatible with ISO30 Rotary ATC Tool Holder
2)Japan Panasonic Servo Motor with Germany Reducer
3)Germany Helical Gear Rack
4)XYZ AIXS use HIWIN/PMI 25MM Guiding Rails
5)Mist sprayer cooling system
6)Vacuum Inhaling table with T Slot table/2sets 7.5KW air cooling vacuum pump
7)dust collector / Auto tool sensor
8)Design Software: Ucancam V9/ Route 8 Type 3/ Artcam
9)Control Software: Weihong NC Studio or Taiwan Syntec ATC Controller.
10)Auto Tool Changer Number: 8 or 10 pcs is optional
11)Packing Size: 4200x2230x1600 mm
12)Gross Weight: 2500KG
Optional Function: CCD Cameral for contour cutting, for cutting printing images.
Optional Model: 1300*2500mm, 2000*3000mm, 2000*4000mm, 2000*6000mm, etc.
Certificate: CE, ISO9001 , SGS
Extra Service:
1) OEM Service is acceptable
2) Machine body design and color can be customize.
3) Machine specifications can be changed according to customer requirements
Other Information:
1)Warranty: 2 years warranty for whole machine
2)Packing: Plywood case with strong Iron steel pallet
3)Delivery: By sea with LCL OR FCL
4)Payment method: by bank transfer or LC
5)Payment terms: 30% deposit before production, pay off 70% balance before shipment
6)Training: Offer technician on-site training and installation/ Life-time technical support is for free.
Control type : CNC
Number of axes : 3-axis
Number of spindles : 1-spindle
Treated material : wood, for wood
Other characteristics : with automatic tool changer
X travel : 1,500 mm (59 in)
Y travel : 3,000 mm (118 in)
Z travel : 150 mm (6 in)
