Do you want to adjust the flow of an electric current in a circuit? This RS PRO resistor has a carbon film and ceramic rod construction to keep electrical current contained and safe.
The film is coated in an adhesive resin that makes it highly resistant to chipping, corrosion and rust. The resistor operates at low noise levels and offers excellent stability against changes in moisture levels and load conditions, so you can use it for a variety of applications.
This product is used in automotive, telecommunication and medical equipment to maximise safety and keep devices running efficiently. It’s Restriction of Hazardous Substances (RoHS) compliant, meaning it contains only minimal amounts of any harmful materials.

Features and Benefits

Operating temperature range of -55°C to +155°C

Temperature coefficient range of -500 ppm/°C to +350 ppm/°C

Carbon film technology

Tolerance of ±5%

The RS series of carbon film axial leaded resistors offer excellent long term stability and feature standard solder-plated copper leads. Applications include automotive, telecommunication and medical equipment.

A comprehensive range of high stability carbon film resistors qualified and tested to the requirements of IEC 115 and IEC 115-2. The ruggedised welded cap and lead method of manufacture provides a considerable strength and resistance to damage. The coating materials and the colour bands are epoxy resin and are highly resistant to solvents, abrasion and chipping. Excellent stability against changes in load conditions or moisture levels, with a low noise level and high reliability make these carbon film resistors suitable for a wide range of applications.

Technology : carbon-film
Mounting : SMD, standard
Other characteristics : rugged
Resistance : 1 Ohm
Power rating : 0.25 W
