Highest Accuracy Three-Axis Detect Lump and Neckdown Detectors

Quickly, reliably detect and locate product flaws, such as lump and neckdowns, before they become costly production problems to ensure maximum quality control.

• Ultra-Fast Flaw Detection – three-axis gauging coupled with fast response circuitry rapidly detects flaw heights down to 0.02 mm at line speeds up to 3000 m/min.
• Continuous Quality Control – effectively monitor and report on critical flaw data and gauge performance to produce the highest quality products
• Flexible Communications – supports a wide range of communication protocols for easy integration into processes
• Lowest TCO – sealed, rugged design minimizes light and dust contamination and provides long, reliable service life
• Preeminent Support – all systems are backed by NDC’s dedicated worldwide customer service organization available 24-7 via myNDC cloud service

High-Precision, Three-Axis Flaw Detection for Continuous Quality Manufacturing

The LN3000 Series 3-axis gauge provides precise detection of short-term faults in the product diameter at higher line speeds than two-axis systems. Two models are available:

• LN3015 for products up to 15 mm in diameter
• LN3040 for products up to 40 mm in diameter

The LN3015 offers ±0.011 mm accuracy, while the LN3040 offers ±0.018 mm accuracy (or ±3% max flaw height).

Both gauges can be easily connected to a host PC or PLC using RS232, Telnet, EtherNet/IP, Ethernet, DeviceNet, Profibus and Profinet.

Applications : for cables
Portability : fixed
