Bevel gear reducerFL series

Onvio’s FL series gearbox is perfect for high dynamic belting applications that put a heavy radial load on the gearbox. Onvio has combined our SL bevel gearbox with our PL flanged gearbox to provide a compact belt drive that can be installed in the tightest spaces. Onvio’s pulleys are made fit in almost any pitch style make the FL a versatile right angle solution for high speed motion control applications.
Additional Features include:
Steel Housing
Carburized spiral bevel gears
Four frame sizes
Carburized and skived spur gearing
Steel housing and ring gear
Backlash as low as 10 arc-minutes
High capacity output bearings
Optional NEMA output dimensions
20,000 hour life
Grease filled for life and maintenance free

Type : bevel, helical, spur
Shaft orientation : right angle
Torque : 20 – 50 Nm, 50 – 100 Nm, 10 – 20 Nm
Performance : low-backlash, high-speed, maintenance-free
Other characteristics : compact, combined
