Integrated tab forming & winding machine for Cylindrical battery
● Application
It is mainly used in the winding of power/energy storage cylindrical batteries.
● Exhibition
● Functional Features
1.It can realize auto upload & download feeding material for electrode and separator , double hanging shaft automatic connecting strip , automatic rectifying, automatic tab welding, automatic sticking auto winding & sticking end tape .
2.Adopting triple switch work stations: station 1 for insert pin & wind; station 2 for cutting separator , ending, taping; station 3 for drawing back needle and download feeding material .
3.Electrode position detect and initially correct functions are provided before winding;
4.Variable speed and variable tension controls functions are provided;
5.Failed Electrode will be winded separately and then removed automatically;
6.With special brushes and vacuum cleaner installed in the cutting place to remove powder and dust and separator remove electrostatic function.
7.The real-time detection function of the electrode alignment degree;
8.With short circuit test function and extend holes automatically
9.The equipment adopts advanced integrated control system to ensure the stability of high-speed operation
Other characteristics : automatic
