Automatic vertical packaging machine designed for intermittent welding of a wide variety of products.

The Matic Vert 520 CP-A vertical machine machine has been specifically designed for continuous motion wrapping of many different product types. The machine is extremely flexible in terms of changing the forming size to allow for different portions, and has the versatility of adapting to any film type.

Features

Stainless steel structure
Servo driven cross seal jaw (1 servomotors)
Servo driven film transport (2 servomotors)
Front and side frame opened construction
Film reel holders with Pneumatic chocks
One piece and easy change film former
Industrial PLC, colour touch screen (Berghoff 10”)
Capacity to program data for 100 items
Touch screen adjustment of sealing time, temperature and pressure for the horizontal seal jaws
Motorised centering of film roll holders
Key controlled Access to different operator level
Motorised film tracking with film tension control with load cells
Film Roll Holders with Pneumatic chocks
Automatic detection for the end of film roll
Film transport with belts and vacuum system with Becker pump
Zig-zag sealing mode
Precision Bag Length Control at High or Low Speed
Precision bag length control at high or low speed
Horizontal seal obstruction detection
Strings or double bag
Automatic detection of irregularities in the sealing temperature or in the pneumatic pressure of the system
Easy interface with peripheral equipment
Designed and manufactured in accordance with the (98/37/CEE) safety regulations

Operational mode : automatic
Type : blister, film, vertical, continuous-motion
Applications : tablet, for bulk materials, for powders
Domain : for the food industry, for the medical industry, for the chemical industry, for the pharmaceutical industry, for the cosmetics industry
Other characteristics : high-rate, with sealing bar, high-speed
