MODEL / PRODUCT FEATURE
> Industrial suspension system for control enclosure
> Modular construction with cable channel
> Wall, top-mounting or floor fixing

The GTKe suspension system is a modular industrial aluminium-profile supporting-arm system for integration of control enclosures.

It is designed for smaller loads of a maximum of 30 kg, with a reach of 1.0 m.

Maximum reach is 1.5 m at a load of 20 kg.

A special feature of the GTKe is the open cable duct in the profiles, which significantly simplifies cable installation.

This cable duct can be closed using a plastic closure element after completion of installation.

Technical Data
Material:Connecting tube: DIN EN 573 EN AW-AlMgSi
Components: DIN EN 1706 EN AC-AlSi12 (Fe)
Cover profile: TPE
Colour:Powder coating, Tube and components in RAL 7035, light grey, Cover profile: RAL 9005, jet black
Ingress protection:IP 54 to EN 60529
Seals:CR and/or PU foam
Free cable passage:Connecting tube 18 mm opening
System components: 53 mm

Options : for control boxes, aluminum, modular
