The DX 5560 Copy router is equipped with a single powerful spindle motor routing head that can cut holes or a variety of shapes in aluminum light alloy metal or PVC material on three sides without turning or moving the material. The table can turn to fixed angles -45° 90 +45° as well as intermediate angles by a manual operation. The DX 5560 is equipped with a variable speed spindle adjusted by inverter and potentiometer which adjust the spindle speed from 1800 to 12000rpm with an optional quick tool change spindle. This router can either copy existing holes or shapes from a fixed template or create new ones. It comes with 3 adjustable copy templates and many additional templates can be added on to the same track to accommodate multiple functions. Additionally, a single large template can be fitted to cover the entire track 2400mm long. The tool changing on the DX 5560 Copy Routing, Milling Boring Machine is quick and easy. This machine is controlled by two handles which move the head from side to side as well as lowering and lifting the motor head up or down by pneumatic power. It is also equipped with four pneumatic horizontal clamps. The machine is built on a rigid heavy gauge steel frame for better stability. This machine will also come with a CNC control. No template is required for a full XYZ operation with 3 or 4 axis. Ferracci Machines USA also manufactures a superb line of hydraulic punch presses, aluminum crimping machine presses, and other equipment for milling and cutting aluminum and PVC.
Materials to be tapped : for aluminum
Other characteristics : 3-axis, universal, CNC
