The AFRDin range is a family of cleaning supplies to single-voltage direct current, especially designed for mounting on DIN rail. According to the model the input network can be 115 VAC, single phase 230 VAC, 230 VAC or 400 VAC three phase. The power factor correction (PFC) according EN61000- 3-2 Class A is also integrated. Compact and powerful, this series has the UL, C-UL and CE marking. This series is ideally suited for all electrical applications like electronic enclosures and the automation industry in general.
Specifications
– Metal housing with DIN rail mounting
– Input voltage 90 to 264 VAC single-phase 115/230 VAC PFC and phase with internal switch (depending on model)
– Supply 230 to 400 Vac three phase
– Frequency from 47 to 63Hz
– Voltage: 12, 24,48 or 110Vdc +/- 5%
– Adjustable voltage with external potentiometer
– This range is convertible into regulated battery charger and filtered on request
– Output regulation: ± 2%
– Residual ripple 83%
– Equipped with non-return diodes (DC models)
– Remote Alarm (G models)
– Green LED signaling: presence output voltage Input / Output: 3750 Vac Input / ground: 1750 Vac Output / ground 500Vdc
– Input protection fuse, limiting the inrush current and RFI filter
– Protection against output short circuits, against overloads and against surges
– Operating Temperature -10 to + 60 ° C
– Natural convection except for the powers of 960W, 1200W and 1500W
– Standards: EN60950, UL / CSA, EN61000-6-2, EN61000-3-2 Class A and CE marking
Type : AC/DC
Output : regulated, smoothed output, stabilized
Other characteristics : with short-circuit protection
