32-bit microcontrollerTS68EN360

Features
• CPU32+ Processor (4.5 MIPS at 25 MHz)
– 32-bit Version of the CPU32 Core (Fully Compatible with the CPU32)
– Background Debug Mode
– Byte-misaligned Addressing
• Up to 32-bit Data Bus (Dynamic Bus Sizing for 8 and 16 Bits)
• Up to 32 Address Lines (At Least 28 Always Available)
• Complete Static Design (0 – 25 MHz Operation)
• Slave Mode to Disable CPU32+ (Allows Use with External Processors)
– Multiple QUICCs Can Share One System Bus (One Master)
– TS68040 Companion Mode Allows QUICC to be a TS68040 Companion Chip and Intelligent Peripheral
(22 MIPS at 25 MHz)
– Peripheral Device of TSPC603e (see DC415/D note)
• Four General-purpose Timers
– Superset of MC68302 Timers
– Four 16-bit Timers or Two 32-bit Timers
– Gate Mode Can Enable/Disable Counting
• Two Independent DMAs (IDMAs)
• System Integration Module (SIM60)
• Communications Processor Module (CPM)
• Four Baud Rate Generators
• Four SCCs (Ethernet/IEEE 802.3 Optional on SCC1-Full 10 Mbps Support)
• Two SMC
• VCC = +5V ± 5%
• fmax = 25 MHz and 33 MHz
• Military Temperature Range: -55°C < TC < +125°C • PD = 1.4W at 25 MHz; 5.25V 2W at 33 MHz; 5.25V Description The TS68EN360 QUad Integrated Communication Controller (QUICC™) is a versatile one-chip integrated microprocessor and peripheral combination that can be used in a variety of controller applications. It particularly excels in communications activities. The QUICC (pronounced “quick”) can be described as a next-generation TS68302 with higher performance in all areas of device operation, increased flexibility, major extensions in capability, and higher integration. Type : 32-bit
