Railway Motion Control Unit (RMCU)

The Railway Motion Control Unit – RMCU is a high-performance strapdown system that was developed for Railway application in order to determine absolute orientation (Heading, Pitch and Roll) and parameters of motion (Angular Rates and Linear Accelerations) for any Railway Platforms on which it is mounted. Orientation is determined with high accuracy for both motionless and dynamic applications.

The Inertial Labs RMCU utilizes 3-axes each of precision MEMS accelerometers, miniature Fluxgate magnetometers and MEMS gyroscopes to provide accurate Heading, Pitch and Roll of the device under measure. Integration of gyroscopes’ output provides high frequency, real-time measurement of the device rotation about all three rotational axes. Accelerometers and Fluxgate magnetometer measure absolute, very accurate in static and dynamic conditions Pitch, Roll and Heading/Azimuth at RMCU initial alignment as well as providing ongoing corrections to gyroscopes during operation.

Number of axes : 3-axis
Motor type : linear
Other characteristics : high-performance
Product applications : measurement, motion control
