For the C-885 PIMotionMaster Modular Controller System
• For 3-phase linear motors
• Output current 5 A
• 20-kHz control bandwidth
• BiSS interface for absolute encoders
• Protection against overload, overcurrent, overtemperature

Motor control, servo control, and protective functions
1 motor channel, 1 sensor channel. For three-phase linear motors with currents of 5 A per phase. Sine-commutated operation, field-oriented current control. Automatic adjustment of the commutation angle. PID controller for position and velocity. Protection for motor and motor driver due to protective shutdown and current limitation.

Plug-and-play installation in the C-885 PIMotionMaster
Can be inserted in any free slot. Automatic detection and external communication (USB, Ethernet) by the processor and interface module of the C-885. Can be expanded with optional digital inputs and outputs. Power via the power supply of the C-885.

Encoder inputs
Differential signal transmission for digital (A/B) or analog (sin/cos) encoder signals. Supports BiSS interface for absolute encoders. TTL inputs for limit and reference switches.

Accessories required for digital inputs and outputs
C-885.AA01 adapter board and C-885.iD digital interface module.

Number of axes : 2-axis
Motor type : linear, three-phase
Signal type : digital, Ethernet, analog, USB, encoder
Technology : PID
Other characteristics : modular
Product applications : slot
