Inclination Sensor IP68 Aluminum Housing with 1 axis or 2 axes in MEMS technology with High resolution

Description

TLA200 is an inclinometer with very high performance. The working principle is based on a MEMS sensor with high performance in terms of resolution, long term stability and temperature characteristics.

Easy and reliable angular measurement in:

• Construction equipment and agricultural machinery
• Drilling machinery
• Crane and lifting technology
• Telescopic Forklift trucks
• Automation technology
CHARACTERISTICSMEMS technologyHigh protection level IP68 and wide temperature range from -40°C … +85°CStable accuracy over whole temperature rangeResolution up to 0,01°Single axis 0° to 360°Double axes ± 1° to ± 60°Optional redundant outputADVANTAGESSimple selection and fast installationReliability and long service life for outdoor applica-tionsHigh shock resistanceDifferent output types (analog, CANopen, TTL output).Customized solution on requestRobust anticorodal anodized housing
TECHNICAL SPECIFICATIONMeasuring range±1° to ±60° for horizontal version0° to 360° for vertical versionLinearityHorizontal < ±0,5 % FSVertical < ±0,5 °Resolution0.01°Temp. range compensation-10°... +60° (custom on request)Temperature coefficient0,005 °/°CProtectionIP68Temperature range-40°C ... +85°C [-40°F ...+185°F]Material housingAnticorodal aluminum anodizedWeightapprox. 325 g [11.46 oz] Shock resistanceacc. to EN 60068-2-27 30 G, 11 msVibration resistanceacc. to EN 60068-2-6 20 G, 10 ... 500 Hz Number of axes : 1-axis, 2-axis Output : CANopen, analog, TTL Technology : MEMS Other characteristics : high-resolution, with aluminum housing, rugged, IP68 Inclination : Min.: Resolution : 0.01 °
